Euro-Locks a Lowe & Fletcher group Company Panel to Tongue Depth 28.5mm Plunger Lock, Key to unlock
- RS Stock No.:
- 0752212
- Mfr. Prt No.:
- 4282-1400BA
- Brand:
- Euro-Locks a Lowe & Fletcher group Company
Legislation and Compliance
RoHS Status: Not Applicable
Statement of Conformity
This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.
| RS stock number | 0752212 |
| Product description | Euro-Locks a Lowe & Fletcher group Company Panel to Tongue Depth 28.5mm Plunger Lock, Key to unlock |
| Manufacturer / Brand | Euro-Locks a Lowe & Fletcher group Company |
| Manufacturer part number | 4282-1400BA |
The foregoing information relates to product sold on, or after, the date shown below.
RS COMPONENTS
| Date | Apr 23, 2024 |
RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132
Country of Origin: GB
Product Details
Plunger Lock
Very useful on equipment with sliding access panels or to secure machine guards
12.5mm spring loaded shoot
Fixing is by rivets or security screws
Bright chrome finish
Zinc plated key available separately; key size 8mm
Specifications
| Attribute | Value |
| Brand | Euro-Locks a Lowe & Fletcher group Company |
| Unlock Method | Key |
| Panel To Tongue Depth | 28.5 mm |
| Panel Cut Out | 24.2 x 20 mm |
| Maximum Panel Thickness | 28.5 mm, - |
| Panel Cut Out Length | 24.2 mm |
| Panel Cut Out Width | 20 mm |
