Belden Right Angle Female M8 to Free End Sensor Actuator Cable, 4 Core, PVC, 2m

RS Stock No.:
1615681
Mfr. Prt No.:
RKMWV 4-07/2,0 M
Brand:
Belden

Technical Reference

Legislation and Compliance

RoHS Status: Not Applicable

Statement of Conformity

RS Components
Statement of Conformity

This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.

Compliant Product Details
RS stock number 1615681
Product description Belden Right Angle Female M8 to Free End Sensor Actuator Cable, 4 Core, PVC, 2m
Manufacturer / Brand Belden
Manufacturer part number RKMWV 4-07/2,0 M

The foregoing information relates to product sold on, or after, the date shown below.

RS COMPONENTS

Date Mar 29, 2024

RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132

Country of Origin: DE


Product Details

Leads with angled female M12/M8 plug

From Lumberg, these right-angled sensors leads feature a locking nut that assures a high degree of environmental protection and stability when mated. Ideal for use in industrial automation, the leads are available with either an M12 or M8 female plug at one end.


Specifications

Attribute Value
Brand Belden
Connector B Free End
Series RKMWV
Connector A Number of Contacts 4
Connector A Gender Female
Plug/Socket Socket
Connector A M8
Connector A Orientation Right Angle
Body Orientation Right Angle
Coding A
Number of Cores 4
Length 2 m
Sheath Material PVC
Sheath Colour Orange
IP Rating IP65, IP67
Cross Sectional Area 0.25 mm²
Voltage Rating 30 V
Conductor Material Copper
American Wire Gauge 24 AWG
Insulation Material PVC
Oil Resistant Yes
Outer Diameter 5 mm
